89www.behnke-online.de
GB
Instructions SIP intercoms series 20-0001BS, 20-0014BS, 20-0016BS
Commissioning and configuration
Link-local = self-assignment of an address
This address assignment is intended for networks without a DHCP server. The device assigns itself
a free IP address in the network 169.254.0.0/16. The assigned IP address can 268 configuration
steps BEHNKE-STATION 3.00 can be queried by pressing the configuration key twice. This type of
address assignment is used when several devices are operated in an independent network as an
IP intercom station.
If there is a DHCP server in the network that assigns an IP address, then this IP address will be used.
In this case, 'dynamic' should be set as address assignment!
Important!
In networks with DHCP server, 'dynamic' should be selected as address assignment!
IP configuration with static address assignment Default: 192.168.100.100
76 IP address # Default: 192.168.100.100
77 Subnet mask # Default: 255.255.255.0
78 Gateway #
Here you can set the IP configuration that the device uses when the IP address assignment is set to
static. During input, points are entered by pressing the * key.
VLAN tag Default: 1
79 1 # Day 1
: :
4094 # Tag 4094
Here you can set the VLAN tag that will be used for the device's VLAN when 'VLAN' or 'VLANs for
device and webcam' is set as the network connection.
Perform action Default: 0
97 0 # Disable online log and online support
1 # Enable online log and allow online support
2 # Send diagnostic data to support
3 # Send trace to support
4 # Restart system
5 # Activate inactive slot
Various actions can be triggered via this configuration step.
To enable us to provide you with optimum support in the event of a support case, you can transfer
diagnostic data and network traces directly to our support server here. After consultation with our
support, you can also enable us to remotely access your device via configuration step 97 1 #.
