Telemark Cryogenics Microprocessor Based Cryochillers
Page
37
of
63
Revision 1.0.7 October 2018
Note:
Once the host IP address has been changed the
board the TCPIP “GUI” will no longer respond until
changes have been made to the remote computer IP
addressing has been made to suit (see 2.8.1 above).
The default IP address is 192.168.1.100
Save to File
– saves currently displayed and logged information to file.
The data is saved as .TXT format.
Open File
– opens previously saved data.
Com
– drop down window to setup currently used RS232 or RS484
computer communications port.
Send
– enquiry/command strings entered here followed by enter (eg.
Typing “rsn” <CR> will return the serial number of the unit on the main
screen.
