Telit Wireless Solutions ME910G1 Series User Manual

ME910G1 HW Design Guide
1VV0301593 Rev.3 Page 19 of 97 2020-03-24
DIGITAL IO
C8
GPIO_01
I/O
GPIO_01 /STAT LED
CMOS 1.8V
STAT LED
is alternate
function
internal PD
(100K)
C9
GPIO_02
I/O
GPIO_02
CMOS 1.8V
internal PD
(100K)
C10
GPIO_03
I/O
GPIO_03
CMOS 1.8V
internal PD
(100K)
C11
GPIO_04
I/O
GPIO_04
CMOS 1.8V
internal PD
(100K)
B14
GPIO_05
I/O
GPIO_05
CMOS 1.8V
internal PD
(100K)
C12
GPIO_06
I/O
GPIO_06
CMOS 1.8V
internal PD
(100K)
C13
GPIO_07
I/O
GPIO_07
CMOS 1.8V
internal PD
(100K)
K15
GPIO_08
I/O
GPIO_08
CMOS 1.8V
internal PD
(100K)
L15
GPIO_09
I/O
GPIO_09
CMOS 1.8V
internal PD
(100K)
G15
GPIO_10
I/O
GPIO_10
CMOS 1.8V
internal PD
(100K)
ADC
B1
ADC_IN
AI
Analog Digital Converter
input
