Telit Wireless Solutions ME910X1 User Manual

ME910C1 mPCIe HW Design Guide
1VV0301642 Rev. 2 Page 10 of 56 2022-01-14
Not Subject to NDA
TX Output Power
Technology
Power (dBm)
2G LB
32 (when available)
2G HB
29 (when available)
4G FDD
23 @1RB
Table 3: TX Output Power
RX Sensitivity
Technology
Sensitivity (dBm)
2G
-107 (when available)
4G FDD (BW=5 MHz)
-102
Table 4: RX Sensitivity
Mechanical Specifications
2.7.1. Dimensions
The overall dimensions of ME910X1-mPCIe family are:
• Length: 50.95 mm, +0/-0.3mm
• Width: 30 mm, +0/-0.3mm
• Thickness : 3.2 mm, +/-0.15mm (Version with SIM holder : 4.78 mm, +/-0.15mm)
2.7.2. Weight
The nominal weight of the mPCIe card is about 7 grams.
Temperature Range
Case
Range
Note
Operating Temperature
Range
–20°C ~ +55°C
The module is fully functional(*) in all the temperature range, and
it fully meets the 3GPP specifications.
–40°C ~ +85°C
The module is fully functional (*) in all the temperature range.
However, there may be some performance deviations in this
extended range relative to 3GPP requirements, which means that
some RF parameters may deviate from the 3GPP specification in
the order of a few dB.
For example: receiver sensitivity or maximum output power may be
slightly degraded
