ME910C1 mPCIe HW Design Guide
1VV0301642 Rev. 2 Page 48 of 56 2022-01-14
13. REFERENCE TABLE OF RF BANDS CHARACTERISTICS
PCS 1900 1850.2 ~ 1909.8 1930.2 ~ 1989.8 512 ~ 810 80 MHz
DCS 1800 1710 ~ 1785 1805 ~ 1880 512 ~ 885 95 MHz
GSM 850 824.2 ~ 848.8 869.2 ~ 893.8 128 ~ 251 45 MHz
EGSM 900
890 ~ 915 935 ~ 960 0 ~ 124 45 MHz
LTE 2100 – B1 1920 ~ 1980 2110 ~ 2170
Tx: 18000 ~ 18599
190 MHz
LTE 1900 – B2 1850 ~ 1910 1930 ~ 1990
Tx: 18600 ~ 19199
80 MHz
LTE 1800 – B3 1710 ~ 1785 1805 ~ 1880
Tx: 19200 ~ 19949
95 MHz
LTE AWS – B4 1710 ~ 1755 2110 ~ 2155
Tx: 19950 ~ 20399
400 MHz
LTE 850 – B5 824 ~ 849 869 ~ 894
Tx: 20400 ~ 20649
Rx: 2400 ~ 2649
45 MHz
LTE 2600 – B7 2500 ~ 2570 2620 ~ 2690
Tx: 20750 ~ 21449
120 MHz
LTE 900 – B8 880 ~ 915 925 ~ 960
Tx: 21450 ~ 21799
Rx: 3450 ~ 3799
45 MHz
LTE 1800 – B9 1749.9 ~ 1784.9 1844.9 ~ 1879.9
Tx: 21800 ~ 2149
95 MHz
LTE AWS+ – B10 1710 ~ 1770 2110 ~ 2170
Tx: 22150 ~ 22749
400 MHz
LTE 700a – B12 699 ~ 716 729 ~ 746
Tx: 23010 ~ 23179
30 MHz
LTE 700c – B13 777 ~ 787 746 ~ 756
Tx: 23180 ~ 23279
-31 MHz
LTE 700PS – B14 788 ~ 798 758 ~ 768
Tx: 23280 ~ 23379
Rx: 5280 ~ 5379
-30 MHz
LTE 700b – B17 704 ~ 716 734 ~ 746
Tx: 23730 ~ 23849
30 MHz
LTE 800 – B19 830 ~ 845 875 ~ 890
Tx: 24000 ~ 24149
45 MHz
LTE 800 – B20 832 ~ 862 791 ~ 821
Tx: 24150 ~ 24449
-41 MHz
LTE 1500 – B21 1447.9 ~ 1462.9 1495.9 ~ 1510.9
Tx: 24450 ~ 24599
48 MHz
LTE 1900+ – B25 1930 ~ 1995 1850 ~ 1915
Tx: 26040 ~ 26689
Rx: 8040 ~ 8689
80 MHz
