ME910C1 mPCIe HW Design Guide
1VV0301642 Rev. 2 Page 35 of 56 2022-01-14
Not Subject to NDA
7. RF SECTION
Bands Variants
Please refer to the table provided in section 2.2
TX and RX Characteristics
Please refer to the Module’s Hardware User guide for the details
Antenna Requirements
7.3.1. Antenna Connectors
The ME910X1 Mini PCIe adapter is equipped with a set of 50 RF U.FL. connectors from
Hirose U.FL-R-SMT-1.
The available connectors are:
Main RF antenna (ANT)
GNSS Antenna (GPS)
See the picture on the right for their position on the
interface.
The presence of all the connectors is depending on the
product characteristics and supported functionalities.
For more information about mating connectors search
fo RF U.FL female cable up to 3GHz.
For example the U.FL-LP-xxx from Hirose
https://www.hirose.com/
Figure 12 U.FL Antenna Connectors
The antenna connection is one of the most important aspect in the full product design as
it strongly affects the product overall performances, so please read carefully and follow
the requirements and the guidelines for a proper design.
The ME910X1-mPCIe adapter is provided with three RF connectors.
The available connectors are:
