ME910C1 mPCIe HW Design Guide
1VV0301642 Rev. 2 Page 27 of 56 2022-01-14
Not Subject to NDA
The following flow chart shows the proper “MODEM RESTART” procedure:
Figure 7:
Modem RESTART
AT#SYSHALT
Delay > 15s
END
Delay > 200ms
Delay > 5s
Modem START AT CMD
Modem START AT CMD
W_DISABLE_N -> LOW
or
PERST_N -> LOW
W_DISABLE -> HIGH
and
PERST_N -> HIGH
