CONFIGURATION SETTINGS | 25
Bit 1 Bit 2 Conguration Setting Value
ON ON Adapt + Fixed EQ (Use SETTING Bits #1, 2, 3, 4 to
set the Fixed levels)
You can separately specify the level of adjustment in the EQ HI and EQ LO frequency bands
when the DDEQ mode is congured for Fixed EQ mode. SETTINGS Bits #1 and #2 control
the dB adjustment for the EQ HI band, and Bits #3 and #4 control the dB adjustment for the
EQ LO band as follows:
SETTINGS
Bit 1 Bit 2 Conguration Setting Value
OFF OFF 0 dB adjustment, EQ LO [Factory Default]
OFF ON +2 dB adjustment, EQ LO
ON OFF +4 dB adjustment, EQ LO
ON ON +6 dB adjustment, EQ LO
SETTINGS
Bit 3 Bit 4 Conguration Setting Value
OFF OFF 0 dB adjustment, EQ HI [Factory Default]
OFF ON +2 dB adjustment, EQ HI
ON OFF +4 dB adjustment, EQ HI
ON ON +6 dB adjustment, EQ HI
You are encouraged to try varying levels of EQ boost to make your telephone audio warmer and
clearer. Our factory default settings should be considered a safe starting point. Because tastes
and situations dier, we don’t presume to make those choices for you. Our testing does suggest
that utilizing the full 6 db boost works well in most cases, dramatically enhancing telephone
audio.
We suggest that you set up your phones like you would any other audio processing device: adjust
and listen critically and repeat this process until you’re satised.
Ducker Conguration settings
SETTINGS Bits #5 and #6 control the overall operation of the Ducker processing function.
You can select between full-duplex (no ducking), -6 dB, -12 dB, or half-duplex (one way at a
time) using the following bit settings:
SETTINGS
Bit 5 Bit 6 Conguration Setting Value
OFF OFF Full Duplex (no attenutation)
OFF ON -6 dB attenuation [Factory Default]
ON OFF -12 dB attenuation
ON ON Half Duplex
