CONFIGURATION SETTINGS | 29
Bit 1 Bit 2 Bit 3 Bit 4 Telephone Network
ON OFF OFF ON Custom country conguration
ON OFF ON OFF Custom country conguration
ON OFF ON ON Reserved for future use
ON ON OFF OFF Reserved
ON ON OFF ON Reserved
ON ON ON OFF Reserved
ON ON ON ON Reserved
TABLE 2 – Internal DIP Switch bank
Bit 5 Bit 6 Bit 7 Bit 8 CPTD Signal characteristics
OFF OFF OFF OFF US dial tone
OFF OFF OFF ON US re-order signal
OFF OFF ON OFF WORLD, single freq. Dial tone
OFF OFF ON ON WORLD, Re-order, ON=155 - 550, OFF=155 – 550 msec
OFF ON OFF OFF WORLD, Re-order, ON=250 - 1200, OFF=250 – 1200 msec
OFF ON OFF ON WORLD, multi-tone dial tone
OFF ON ON OFF WORLD, multi-tone dial tone
OFF ON ON ON WORLD, pulse dial tone, ON=150 - 350, OFF=450 – 1100 msec
ON OFF OFF OFF WORLD, pulse dial tone, ON=100 - 250, OFF=200 – 400 msec
ON OFF OFF ON Reserved for future use
ON OFF ON OFF Reserved
ON OFF ON ON Reserved
ON ON OFF OFF Reserved
ON ON OFF ON Reserved
ON ON ON OFF Reserved
ON ON ON ON CPTD feature is disabled
Table 3 - Recommended Internal DIP Switch for each Country
Country Bit 1 Bit 2 Bit 3 Bit 4 Bit 5 Bit 6 Bit 7 Bit 8
Argentina OFF OFF ON OFF OFF OFF ON OFF
Australia ON OFF OFF ON OFF OFF ON ON
Austria OFF OFF ON ON OFF OFF ON OFF
Bahrain OFF OFF ON OFF OFF OFF ON OFF
Belgium OFF OFF ON ON OFF OFF ON OFF
Brazil OFF OFF OFF ON OFF OFF ON OFF
Bulgaria OFF ON ON ON OFF ON ON ON
