TELOS HX1/HX2 MANUAL | V
5 AES I/O Option 33
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . 33
AES Channel Assignments . . . . . . . . . . . . . . . . . . . . . . . . 35
Restoring an AES equipped unit to Analog Operation . . . . . . . . . . . . 35
6 Troubleshooting 37
On-Board Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Software Version . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
DIP Switch Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
T1 Test – 400 hz tone generation . . . . . . . . . . . . . . . . . . . . . 38
T2 Test – Studio Loopback . . . . . . . . . . . . . . . . . . . . . . . . 38
T3 Test – Feed Through Test . . . . . . . . . . . . . . . . . . . . . . . . 39
Hardware Repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
7 Specications 41
8 Warranty and Application Caution 43
A1 Telephone Terminology Guide A1
A2 Quick Reference Guide: Rear Panel Switches A19
A3 Quick Reference Guide: Internal Switches & Remote Connector pin usage A21
