Chapter 3 - Operation and AdministrationBTS Menu
Chapter 3: Operation and Administration
BTS Menu
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BreezeCOMPACT System ManualBreezeCOMPACT System Manual
64
3.5.4.1.1.4 Enable Traps Distribution
Indicates whether the sending of traps to the management station is enabled or disabled.
3.5.4.1.2 Select
Use this option to select one of the existing SNMP Traps Managers by its IP address. You can then view the details of the
selected Manager, update its parameters (excluding the IP address) or delete it.
The Selected Manager submenu includes the following options:
Show: For viewing the details of the selected Manager.
Update: For updating the properties of the selected Manager (for details, see “Add” on page 63 above).
Delete: For deleting the selected Manager from the database.
3.5.4.1.3 Show Summary
Select this option to view the details of the currently defined SNMP Traps Managers.
3.5.4.2 Authorized Managers
An SNMP Manager comprises a pair of SNMP Communities (Community Read Only and Community Read and Write). A
management station is permitted to manage the BTS using SNMP only if it uses one of the configured SNMP Communities
(or a pair of SNMP Communities). A maximum of 5 SNMP Managers can be configured. The Authorized Managers
submenu enables you to define the properties of management stations that are allowed to manage the BTS using SNMP.
By default, the unit is supplied with one authorized manager with the following parameters:
Manager Number: 1
Community Read Only: public
Community Read and Write: private
The Authorized Manager submenu includes the following options:
Add
Select
3.5.4.2.1 Add
Select this option to add a new Authorized Manager. Up to 5 Authorized Managers can be defined. The following parameters
can be configured:
Manager Number
Community Read Only
Community Read and Write
3.5.4.2.1.1 Manager Number
A unique number from 1 to 5.
