- 6 -
feedingbuildingsfordomesticuse.
EXTRA PRECAUTIONS
- WELDINGOPERATIONS:
- Inenvironmentswithincreasedriskofelectricshock;
- Inconnedspaces;
- Inthepresenceofammableorexplosivematerials;
MUSTBEevaluatedinadvancebyan“Expertsupervisor”andmustalways
be carried out in the presence of other people trained to intervene in
emergencies.
AllprotectivetechnicalmeasuresMUSTbetakenasprovidedin7.10;A.8;
A.10oftheapplicablestandardEN60974-9:Arcweldingequipment.Part9:
InstallationandUse”.
- Welding MUST NOT be allowed if the welding machine or wire feeder is
supportedbytheoperator(e.g.usingbelts).
- The operator MUST NOT BE ALLOWED to weld in raised positions unless
safetyplatformsareused.
- VOLTAGE BETWEEN ELECTRODE HOLDERS OR TORCHES: working with
more than one welding machine on a single piece or on pieces that are
connected electrically may generate a dangerous accumulation of no-load
voltagebetweentwodifferentelectrodeholdersortorches,thevalueofwhich
mayreachdoubletheallowedlimit.
An expert coordinator must be designated to measuring the apparatus to
determine if any risks subsist and suitable protection measures can be
adopted,asforeseenbysection7.9oftheapplicablestandard”EN60974-9:
Arcweldingequipment.Part9:InstallationandUse”.
- Theuseofthemachinemustbelimitedtotheoperatoronly.
- The operator must disconnect the cable and theelectrodeholder from the
machineoncetheMMAweldingisover.
- Theareaaroundtheweldingmachinemustbeforbiddentothird parties.It
alsoshouldnotbeleftunattended.
- Thetorchesnotinuseshouldbestoredintheirhousing.
RESIDUAL RISKS
- OVERTURNING:positiontheweldingmachineonahorizontalsurfacethatis
abletosupporttheweight:otherwise(e.g.inclinedorunevenoorsetc.)there
isdangerofoverturning.
- IMPROPER USE: it is hazardous to use the welding machine for any work
otherthanthatforwhichitwasdesigned(e.g.de-icingmainswaterpipes).
- IMPROPERUSE:theusetheweldingmachinebymorethanoneoperatorat
thesametimemaybedangerous.
- MOVING THE WELDING MACHINE: Always secure the gas bottle, taking
suitableprecautionssothatitcannotfallaccidentally(ifused).
- Donotusethehandletohangtheweldingmachine.
Thesafetyguards and moving partsofthe covering of theweldingmachine
andofthewirefeedershouldbeintheirproperpositionsbeforeconnectingthe
weldingmachinetothepowersupply.
WARNING!Anymanualoperationcarriedoutonthemovingpartsofthewire
feeder,forexample:
- Replacingrollersand/orthewireguide;
- Insertingwireintherollers;
- Loadingthewirereel;
- Cleaningtherollers,thegearsandtheareaunderneaththem;
- Lubricatingthegears.
SHOULD BE CARRIED OUT WITH THE WELDING MACHINE SWITCHED OFF
ANDDISCONNECTEDFROMTHEPOWERSUPPLYOUTLET.
2.INTRODUCTIONANDGENERALDESCRIPTION
This welding machine is a source of current for arc welding, made specically for MAG
welding carbon steel or weak alloys with CO
2
protective gas or Argon/CO
2
mixes,
using tubular full or core electrode wires.
It is also ideal for MIG welding stainless steel with Argon gas containing + 1-2%
oxygen and aluminium and CuSi3, CuAl8 (brazing) with Argon gas, using electrode
wires that are suitable for the workpiece to be welded.
It is particularly suitable for light metalwork fabrication and in body shops, for welding
galvanized plates, high stress stainless steel and aluminium. SYNERGIC operation
ensures fast and easy welding parameter setting, always guaranteeing high arc
control and welding quality.
The welding machine is designed for use with the SPOOL GUN torch, used to weld
aluminium and steel in the presence of wide spaces between the generator and the
piece to be welded.
The welding machine can be used for TIG welding in direct current (DC), with arc
striking upon contact (LIFT ARC mode). It welds all types of steel (carbon, low- and
high-alloy) and heavy metals (copper, nickel, titanium and their alloys) with a gas
shield of pure (99.9%) Ar or, for special uses, with an Argon/Helium mix. It can also be
used for MMA electrode welding in direct current (DC) using coated electrodes (rutile,
acid, basic).
2.1MAINCHARACTERISTICS
MIG-MAG
- Operating modes:
- manual;
- synergic;
- AB Pulse;
- AB PoP;
- Root Mig;
- Wire speed, welding current and voltage shown on the display.
- 2T, 4T, 4T Bi-level, Spot operation selection.
- Automatic acknowledgement of the SPOOL GUN and PUSH PULL.
- Automatic detection of G.R.A. Water cooling system (for the AQUA version only).
TIG
- Start LIFT.
- Welding voltage and current shown on the TFT display.
MMA
- Arc force, hot start adjusting.
- VRD device.
- Anti-stick protection.
- Welding voltage and current shown on the TFT display.
OTHER
- Setting the language.
- Setting the metric or UK system.
- Setting the view mode (standard or easy).
- Possibility to set the machine parameters (voltage, current, wire speed).
- Possibility to save, retrieve, import and export customised software.
- Possibility to record and save welding jobs.
PROTECTIONS
- Thermostatic safeguard.
- Protection against accidental short-circuits caused by contact between torch and
earth.
- Protection against irregular voltage (power supply voltage too high or too low).
- Anti-stick (MMA).
- Protection against low pressure of the water cooling system of the torch (for the
AQUA version only).
2.2STANDARDACCESSORIES
- Torch.
- Return cable complete with earth clamp.
- Torch holder stand.
2.3OPTIONALACCESSORIES
- Argon bottle adapter.
- SPOOL GUN.
- Self darkening mask.
- MIG/MAG welding kit.
- MMA welding kit.
- TIG welding kit.
- PUSH PULL torch.
- PUSH PULL board kit.
- G.R.A. Water cooling system (for 270A version only).
3.TECHNICALDATA
3.1DATAPLATE
The most important data regarding use and performance of the welding machine are
summarised on the rating plate and have the following meaning:
Fig.A
1- EUROPEAN standard of reference, for safety and construction of arc welding
machines.
2- Symbol for internal structure of the welding machine.
3- Symbol for welding procedure provided.
4- Symbol S: indicates that welding operations may be carried out in environments
with heightened risk of electric shock (e.g. very close to large metallic volumes).
5- Symbol for power supply line:
1~ : single phase alternating voltage;
3~ : 3-phase alternating voltage.
6- Protection rating of the covering.
7- Technical specications for power supply line:
- U
1
: Alternating voltage and power supply frequency of welding machine (allowed
limit ±10%).
- I
1max
: Maximum current absorbed by the line.
- I
1eff
: effective current supplied.
8- Performance of the welding circuit:
- U
0
: maximum no-load voltage (open welding circuit).
- I
2
/U
2
: current and corresponding normalised voltage that the welding machine
can supply during welding.
- X : Duty cycle: indicates the time for which the welding machine can supply the
corresponding current (same column). It is expressed as %, based on a 10 min.
cycle (e.g. 60% = 6 minutes working, 4 minutes pause, and so on).
If the usage factors (on the plate, referring to a 40°C environment) are exceeded,
the thermal safeguard will trigger (the welding machine will remain in standby
until its temperature returns within the allowed limits).
- A/V-A/V : shows the range of adjustment for the welding current (minimum
maximum) at the corresponding arc voltage.
9- Manufacturer’s serial number for welding machine identication (indispensable for
technical assistance, requesting spare parts, discovering product origin).
10-
: Size of delayed action fuses to be used to protect the power line.
11-Symbols referring to safety regulations, whose meaning is given in chapter 1
“General safety considerations for arc welding”.
Note: The data plate shown above is an example to give the meaning of the symbols
and numbers; the exact values of technical data for the welding machine in your
possession must be checked directly on the data plate of the welding machine itself.
3.2OTHERTECHNICALDATA:
- WELDINGMACHINE:seetable1(TAB.1)
- MIGTORCH:seetable2(TAB.2)
- TIGTORCH:seetable3(TAB.3)
- ELECTRODE-HOLDERCLAMP:seetable4(TAB.4)
Theweightoftheweldingmachineisgivenintable1(TAB.1).
4.WELDINGMACHINEDESCRIPTION
4.1CONTROL,ADJUSTMENTANDCONNECTINGDEVICES.
4.1.1WELDINGMACHINE(Fig.B)
Atthefront:
1- Control panel (see description);
2- SPOOL GUN torch coupling;
3- SPOOL GUN control cable connector;
4- Positive (+) quick coupling for connecting the welding cable;
5- Negative (-) quick coupling for connecting the welding cable;
6- Earth return cable and clamp;
7- SPOOL GUN (optional);
