Section 3 - Step-By-Step Assembly
Temp-Cast 2000 Installation Manual
16
STEP 6:
Install the lintel course, parts 14, 15 & 16, in order, using a small (3/8”) bead of refractory mortar
on the outside edges of the adjoining parts.
Weights
#14 & #14 ST- 86 lbs
#15 & #16 - 64 lbs
