Temp-Cast 2000 - Page 24

Section 3 - Step-By-Step Assembly 24
Temp-Cast 2000 Installation Manual
STEP 14:
Install the lower front wall of the secondary combustion chamber, part # 27.
Seat this part with the mallet & double-check the position of the side walls - adjust with the
rubber mallet as required.
Weights
#27 - 66 lbs
