Section 3 - Step-By-Step Assembly 26
Temp-Cast 2000 Installation Manual
STEP 16:
Part #29 is installed to complete the secondary combustion chamber, forming the front wall.
These 2 upper walls may have a tendency to lean inward while the mortar is setting. Leaning
can be prevented by making a simple wood jig. Cut a length of 2x4, 11-7/8” long. This piece
will be the "spacer".
Nail this piece to a longer piece of wood. Place the jig on top of the walls, so that the spacer
hangs down and prevents the two walls from leaning inward. (This jig can be left in place until
Step 20.)
Weights
#29 - 126 lbs
