Section 3 - Step-By-Step Assembly 30
Temp-Cast 2000 Installation Manual
STEP 19:
Set the middle heat exchange channels (#s 32 & 33) in place, using a thin joint of refractory
mortar between channels. (If mortar squeezes out on the inside surface of the heat exchange
channels, wipe if off. Keeping the mortar back from the inside edges will prevent having to
reach in to wipe off excess mortar from this area.)
Slightly compress the ceramic fibre using the tie-down and secure these two channels with 2
bands of packing tape, as illustrated. (The packing tape can be left in position when the facing is
being applied and then any visible tape can be cut out.)
Weights
#32 & 33 - 95
