Tenda O3 User Manual

97
After the IEEE 802.1Q VLAN settings take effect, packet with tag will be forwarded to the ports of
the corresponding VLAN according to the VID of the packet, and packet without tag will be
forwards to the ports of the corresponding VLAN according to the PVID of the port.
The following form shows the details about how different link type ports address received packets:
Type of the Port
Type of Received Packets
Transmitted Packets
Packet with Tag
Packet without Tag
Access
Forward the data to the
ports of the
corresponding VLAN
based on the VID in the
tag.
Forward the data to the
ports of the
corresponding VLAN
based on the PVID of
ports
Strip the tag in the packet and then
forward it
Trunk
VID PVID of the port, strip the tag
in the packet and then forward it
VID PVID of the port, retain the tag
in the packet and then forward it
6.5.3 Example of configuring VLAN settings
Networking requirement
You use CPEs to set up CCTV surveillance networks. CPE1 and CPE2 are used to connect to IP
cameras in different places and cannot communicate with each other.
You can assign CPE1 and CPE2 to different VLANs.
Assume that:
− CPE1 is assigned to VLAN10, and CPE2 is assigned to VLAN20.
− The router in the network supports IEEE 802.1Q VLAN and enables two DHCP servers
which belong to VLAN10 and VLAN 20 respectively.

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
