Tenda O3 User Manual

147
----End
If internet users still cannot visit servers in LAN after the configuration, try the following solutions:

Ensure that the WAN IP address of the device is a public IP address, and the internal port you
entered is correct.

Security software, antivirus software, and the built-in OS firewall of the computer that establishes a
server may cause port forwarding function failures. Disable them and try again.
The added rule displays in the port forwarding list. The parameters on the picture below are used
for examples.
After the port forwarding rule takes effect, to access the LAN server:
Enter Protocol name://WAN port IP address:External port in the address bar of a web browser on
a computer over the internet.
Parameters description
Name
Description
Internal IP Address
It specifies the IP address of the host that establishes a server in LAN.
Internal Port
It specifies the service port of the server in LAN.
After you select an Application, this option will be auto populated. You can also
customize it.

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
