Tenda O3 User Manual

148
Name
Description
External Port
It specifies the ports which are enabled for WAN users to visit the corresponding
servers in LAN.
After you select an Application, this option will be auto populated. You can also
customize it.
Protocol
It specifies the protocol type of the selected applications. Select TCP&UDP when you
are not sure.
Application
It specifies the application services established in LAN. The device provides some
common services. After you select an application, the internal and external ports will
be populated.
Action
Click to delete the rule.
8.4.3 Example of configuring port forwarding
Networking requirement
The device is used to bridge to the ISP hotspot for internet access in a house in the countryside,
and the device is set to WISP mode.
Requirement: Family members who are not at home can visit the resources on the web server in
LAN over the internet.
You are recommended to use port forwarding function to solve the problem.
Assume that:
− IP Address of the web server: 192.168.2.100
− Service port (internal port) of the web server in LAN: 80
− External port that this device enables for internet devices: 80
− WAN IP Address of the device: 202.105.11.22

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
