Tenda O3 User Manual

55
5. Click Save, and wait until the device reboots to activate the settings.
Step 2 Perform Step 1 above to set CPE3 to Repeater mode, and bridge to CPE1.
Step 3 Set CPE1 to Repeater mode and bridge to CPE2 and CPE3.
1. Start a web browser on the computer connected to CPE1, and visit 192.168.2.1.
2. Choose Quick Setup to enter the configuration page.
3. Select Repeater mode, and click Next.
4. Select SSIDs of CPE2 and CPE3, and click Next at the bottom of the page.
If there are multiple wireless networks with the same SSID, select the ones with the WLAN MAC
addresses of the CPE2 and CPE3, which are C8:3A:35:15:86:8C and C8:3A:35:01:8C:C9 in this example.

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
