Tenex TX Console - Environmental Requirements; Symbol Descriptions

27
Dimensions (Console)
HEIGHT 6.5 inches / 16.5 centimeters
WIDTH 14.5 inches / 36.8 centimeters
DEPTH 13.5 inches / 34.3 centimeters
WEIGHT 21 lbs.
LCD TOUCH PANEL DISPLAY 12.1 inches diagonal / 280(H) × 218(V)
millimeters 800 x 600 pixels, color
e. ENVIRONMENTAL REQUIREMENTS
The TX System Console should be used in a clean environment that is suitable for surgery.
Environmental requirements are as follows:
f. SYMBOL DESCRIPTIONS
The Table on the following page provides the symbols that are found on the TX Console and
their denitions. These symbols are used to provide quick information or instruction in a limited
space.
It is important to become familiar with these symbols and their denitions before setting up and
operating the TX Console.
Operating Environment
Storage/Transport Environment
TEMPERATURE HUMIDITY ALTITUDE
10˚C TO 35˚C 30% to 85% RH ≤ 2,000 Meters (6,561 feet)
TEMPERATURE HUMIDITY ALTITUDE
+5˚C TO +65˚C 30% to 85% RH ≤ 4,267 Meters (14,000 feet)
