Instruction Manual
Multi 250 - 400K - 500F - 500K - 500 MAR e Accessories
21. MIG PULSE MODE
21.2 setting from the machine panel- Mig Pulse Mode
Setting available for generators Serie “K” and Serie “K + DUO”:
NOTE: material type (B) refers to the wire spool type located inside the
machine
A- select MIG PULSE
B – select material type
C – select wire size
C - with the main knob adjust
the current level or the basic
material tick
21.3 Inductance setting- Mig Pulse Mode
Display shows the increasing or decreasing pourcentage towards the pre-set
(synergic) value
21.4 Arc setting- Mig Pulse Mode
The main knob allows arc setting between -20 (short) and +20 (long).
The -0- value correspond than to the pre-set synergic value.
In the same way you can adjust POST GAS, TIMER, CRATER FILLER
and TRIGGER mode.
A - press until inductance led light on
B – adjust inductance
A -press until arc lenght led light on
B – adjust arc lenght
Pulsed
MIG
Pulsed
MIG
MIG PULS
Pulsed
MIG
MIG PULS
Pulsed
MIG
MIG PULS
MIG PULS
19
