Terex PT-110 - General Structure

3 TECHNICAL DATA
31
PT-110/PT-110F US O&M
2095-479 2013-02
3.1 General Structure
Key
1. Auxiliary Hydraulic Quick Couplers (see section 3.7)
2. Electric Attachment Control Receptacle (see section 4.9)
3. Operator Enclosure (R.O.P.S./F.O.P.S. approved)
4. Diesel Fuel (fill location, right side of machine)
5. Hood (engine cover)
6. Hydraulic Oil (fill location)
7. Engine
8. Drive Motor and Sprocket
9. Undercarriage
10. Quick Attach
11. Bucket
12. Lift Arm
13. Product PIN Plate (on front of operator enclosure)
3
8
5
4
6
7
10
9
11
12
13
1
2
