5 OPERATION
62
5.3 Starting Procedure
Before starting the engine, perform the pre-operation safety checklist. Once com-
plete, you may proceed by following this procedure:
1. Enter machine with lift arms all the way down. Maintain three points of
contact (defined as: one foot and two hands, or one hand and two feet) with
the machine (fig. 5.3-1).
2. Sit down into the operator’s seat and fasten the seat belt.
3. Starting with the throttle in the SLOW (turtle icon) position, push the throttle
1/3 of the way open (toward the rabbit icon).
4. Turn the ignition key to the on position and hold for 6 seconds to “pre-heat”
the engine. While pre-heating, the glow plug operation light will illuminate.
5. Turn the ignition key to the right to start the engine.
6. Let the engine run at low idle for 2 to 3 minutes to warm it.
7. Adjust the rear view mirror for optimum visibility.
8. Set the throttle to desired rpm for operation.
Note: The parking brake is automatically engaged when the engine is turned off,
the operator is not in the operator seat or the lap bar is raised.
5.3-1 5.3-2
Entering or exiting the vehicle under raised lift arms could result in injury
or death. Never allow anyone beneath raised, unsecured lift arms (fig.
5.3-2).
PT-110/PT-110F US O&M
2095-479 2013-02
