7.21 Electrical System
The electrical systems in PT machines are equipped with fuses that help to pro-
tect the electrical components from damage. They are found in the fuse panel
enclosure which is located behind the panel cover in the right rear corner of the
interior of the cab behind the operator seat.
In the event of an electrical malfunction, check the fuse panel. Remove the fuse
related to the component that is not working properly and inspect it. If it appears
damaged in any way, replace it.
2095-488Decal fuse panel
10
AUX
D
AUX
D
AUX
C
5
ALT
HEATER
VALVE
10
AUX
G
AUX
B
5
DISPLAY
RADIO
5
ATTACH
SEAT
PILOT
SEAT
PILOT
2
PILOT
INCLINO-
METER
7.5
LIGHTS
5
HORN
ECMK1
10
STARTER
MACHINE
ECU
30
HEATER
WIPER
3
MAIN
PWR B
MAIN
PWR A
10
PILOT DUMP
DRIVE/LOADER
5
ECU START
OVERIDE
MAIN
PWR C
30
OUTPUT
MODULE
FUEL
SENDER
5
ENGINE
ECM 1
ENGINE
ECM 2
20
ECMK1
ENGINE
5
LOADER
PILOT
DUMP
PROPEL
PILOT
DUMP
5
LH JOYSTICK
BUTTONS
ECM K1
KEY ON PWR
MACHINE
CONTROLLER
MAIN PWR A
MAIN MAIN
MAIN POWER C MAIN POWER B
20
AUX
LOADER
50
GLOW PLUG
ENGINE ECU
BREATHER
HEATER
5
BEACON/
DOME
30
LIGHTS
30
CONDENSOR
20
STARTER
15
AIR RIDE
SEAT
15
IGNITION
20
PWR OUTLET
60 40 50 80 60 50 40
CALIBRATION
JUMPER
ENGINE ECU
CONNECTOR
CAN BUS
CONNECTOR
2095-488 PT110
