Terex PT-110 - Operating Specs, Capacities, and Fluids

3.6 Transmission PT-110 PT-110 F
3.7 Auxiliary Hydraulics PT-110 PT-110 F
3.8 Ground pressure PT-110 PT-110 F
3.9 Operating Specs. PT-110 PT-110 F
Note: The Maximum Gross Vehicle Weight of the PT-110 is not to exceed 16000
lb (7257 kg.). This excludes an operator, but does include accessories,
attachments and material being carried.
3.10 Refill Capacities (approx.) PT-110 PT-110 F
Make
Rexroth Rexroth
Type
A10VG63 A10VG63
Design
Axial piston Axial piston
Displacement
3.84 in.³ (63 cc) / rev. 3.84 in.³ (63 cc) / rev.
Relief Pressure
5500 psi (37,920 kPa) 5500 psi (37,920 kPa)
Make
Rexroth Rexroth
Type
A10VO85 A10VO85
Design
Axial Piston Axial Piston
Displacement
5.19 in. ³ (85 cc) /rev. 5.19 in. ³ (85 cc) /rev.
Relief press. Low Flow
3300 psi (22,750 kPa) 3300 psi (22,750 kPa)
Relief press. High Flow
3800 psi (26,200 kPa) 3800 psi (26,200 kPa)
Low Flow @2200 RPM
0-20 gpm (0-75.7 lpm) 0-20 gpm (0-75.7 lpm)
High Flow @2200 RPM
30-43 gpm (114-163 lpm) 30-43 gpm (114-163 lpm)
At operating weight (18")
4.3 psi (29.7 kPa)
At operating weight (20")
3.9 psi (26.9kPa) 4.25 psi (29.3kPa)
Tipping load
7600 lb (3447 kg) 8600 lb (3901 kg)
Operating capacity 50%
3800 lb (1724 kg) 4300 lb (1950 kg)
Operating capacity 35%
2660 lb (1207 kg) 3010 lb (1365 kg)
Fuel tank
30gal(113.6l) 30gal(113.6l)
Hydraulic tank
22gal(83.3l) 22gal(83.3l)
Engine coolant
4.3gal(16.3l) 4.3gal(16.3l)
Engine oil including filter
9qt.(8.52l) 9qt.(8.52l)
Planetary Drive
.95qt.(.9l) .95qt.(.9l)
33
3 TECHNICAL DATA
PT-110/PT-110F US O&M
2095-479 2013-02
