Terex RL4000 Service Manual

June 2013
Part No. 116694 RL4000 • TML-4000
TABLE OF CONTENTS
Section 5 Schematics
Introduction .................................................................................................. 5 - 1
DC Wiring, Kubota ....................................................................................... 5 - 2
Engine Harness, Kubota.............................................................................. 5 - 3
DC Wiring, Perkins ...................................................................................... 5 - 4
Engine Harness, Perkins ............................................................................. 5 - 5
Wire Harness, Inside Control Box, DC ........................................................ 5 - 6
MH Light Fixture .......................................................................................... 5 - 7
1000 MH Ballast .......................................................................................... 5 - 8
ix
Discount-Equipment.com

Terex RL4000 Specifications

General

Number of Lights	4
Fuel Type	Diesel
Mast Height	9 m (30 ft)
Light Type	LED
Lamps	LED
Illuminated Area	4000 m²
