Terex TSV-80 - General Structure

3 TECHNICAL DATA
33
3.1 General Structure
Key
1. Bucket
2. Lift Arm
3. Operator Enclosure (R.O.P.S./F.O.P.S. approved)
4. Hydraulic Oil (fill location)
5. Diesel Fuel (fill location)
6. Hood (engine cover)
7. Engine
8. Wheel(s)
9. Chain Case
10. Quick Attach
11. Product PIN Plate (on front of operator enclosure)
1
2
3
8
6
5
4
7
10
9
11
8
