Terex TSV-80 - Removal From Storage

79
7.21 Electrical System
The electrical systems in TSV machines are equipped with fuses that help to pro-
tect the electrical components from damage. They are found in the fuse panel
enclosure which is located behind the panel cover in the right rear corner of the
interior of the cab behind the operator seat.
In the event of an electrical malfunction, check the fuse panel. Remove the fuse
related to the component that is not working properly and inspect it. If it appears
damaged in any way, replace it.
40
40
50
20
30
20
20
30
3
5
5
10
5
10
5
25
10
10
15
5
10
35 A. RELAY
35 A . RELAY
#G8V-RH-1C7T-R-
DC12
10
5
PWR RELAY A
PWR RELAY B
GLOW PLUG
STARTER
PWR OUTLET
AUX LDR
A/C
35 A. RELAY
SAFETY
LIGHTS STARTER
IGNITION
ENABLER SOL
INJ. PUMP
TWO SPD
BKUP ALM
ALT
HRN-
LT
-SW
HEATER
RADIO
BEACON
ALT. DIODE
WIPER
MICRO SW
ELECTRICAL PANEL
SKIDSTEER TS 70/80 7005-600
HTR VLV
SELF LEV
40 A . RELAY
# 87417B
GLOW PLUG
40 A . RELAY
# 87417B
AUX LDR G
40 A . RELAY
# 87417B
AUX LDR C
40 A . RELAY
# 87417B
AUX LDR D
40 A . RELAY
# 87417B
AUX LDR B
LIGHTS
FLOAT MAG
60
80
MAIN
MAIN
MAIN PWR B
MAIN PWR A
35 A . RELA Y
#G8V-RH-1C7T-R-
DC12
35 A . RELAY
#G8V-RH-1C7T-R-
DC12
#G8V-RH-1C7T-R-
DC12
#G8V-RH-1C7T-R-
DC12
7 MAINTENANCE
