73
7.12 Air Cleaner Removal / Inspection
The air cleaner is one of the most
important maintenance items on the
machine. Regular inspection and
replacement is necessary to ensure
proper performance and to prolong
engine life. Inspect the air cleaner
elements daily. If damaged or heavily
soiled, clean or replace the elements.
1. Shut the machine down as described in section 5.13, then open the hood
and rear door to access the air cleaner housing.
2. Unlatch and remove the housing cover (1) as shown.
3. Remove the primary element (2). The primary element can be cleaned and
reused up to five times, but should be changed at least once a year.
4. Remove the secondary element (3). The secondary element is not
serviceable or washable. The secondary element should be replaced after
every three cleanings of the primary element.
2
1
3
7.12-1 7.12-2
7.12-3
7 MAINTENANCE
