Terex TSV-80 User Manual

3.6 Auxiliary Hydraulics TSV-70 TSV-80
3.7 Operating Specs. TSV-70 TSV-80
Note: ISO 14397:1 defines operating capacities of rubber tired skid steer loaders
as 50% of tipping load.
3.8 Refill Capacities (approx.) TSV-70 TSV-80
3.9 Fluid Specifications
3.10 Dimensions and Weights TSV-70 TSV-80
System Pressure Max.
3300 psi (22750 kPa) 3300 psi (22750 kPa)
Controls
Hydraulic Pilot Joystick Hydraulic Pilot Joystick
Couplers
3/4" Flat Faced 3/4" Flat Faced
Flow
(
2500 RPM
)
26
gp
m
(
98 l
p
m
)
26
gp
m
(
98 l
p
m
)
Tipping load
5270 lb (2390 kg) 6000 lb (2722 kg)
Operating capacity
2653 lb (1203 kg) 3000 lb (1361 kg)
Fuel tank
30gal(113l) 30gal(113l)
Hydraulic tank
10gal(38l) 10gal(38l)
Engine coolant
3gal(11l) 3gal(11l)
Engine oil including filter
9qt(8.52l) 9qt(8.52l)
35
3 TECHNICAL DATA
Specifications
Desi
g
nation
Specification/standard
Fuel
Diesel Fuel
EN590 or ASTM D975 1-D / 2-D
Engine Oil
Engine Oil
SAE 10W-30 (API CH-4)
Engine Coolant
Coolant
Antifreeze/Water w/SCA additive
Hydraulic Oil
Hydraulic Oil
Mobil DTE 10 Excel Series 46
Lubricatin
g
Points
MP Grease
Multi-
p
ur
p
ose lithium
g
rease
Lengthw/bucket 144in(3658mm) 144in(3658mm)
Width 72in.(1828mm) 72in.(1828mm)
Height(totopofcab) 82.75in.(2102mm) 82.75in.(2102mm)
GroundClearance 10in.(254mm) 10in.(254mm)
Weight(operating) 8100lb(3674kg) 8600lb(3901kg)

Terex TSV-80 Specifications

General

Brand	Terex
Model	TSV-80
Category	Compact Loader
Language	English
