The embedded tracker detects and tracks any moving object. It gives the operator
an overview of moving objects, which the normal radar video alone cannot provide.
The tracker combines the information from the different Doppler filter channels with
the scan-to-scan movements in the normal video to achieve separation of small
moving targets from ground clutter.
2.2.2 Physical appearance of SCANTER 1002
Fig. 2.4 Transceiver dimensions (model)
Weight: 35 kg installed
~ 50 kg packed for transportation
H x W x D 850 x 500 x 500 mm installed
~ 1090 x 800 x 600 mm packed for transportation
