TERMA SCANTER 1002 - GND Connection

Page 25/62
Rev. A
2017-12-04
SCANTER 1002 Radar System
User’s Manual
1255194-HO
4.4 GND
The ground stud is for connection to Protective Earth.
Fig. 4.2 Bottom plate, ground stud
Terminal Function Terminal Function
1BI_DA+ 6BI_DB-
2 BI_DA- 7 BI_DD+
3 BI_DB+ 8 BI_DD-
4 BI_DC+ SHELL Shield
5 BI_DC-
