7 BITE errors and warnings
The following lists BITE errors and warnings that may be detected in the system.
Please note that the list is not exhaustive. For a complete list of errors and warn-
ings, please refer to doc. 721086-DI “SCANTER 1000 Series Transceiver Control
Protocol Data Definition - Service Access Mode”.
Name Min Max Severity Description
ADC Calibration Error Error
Antenna RPM Too Large Error Error
Error indicating that 'Antenna RPM' parameter value is larger
than 'Maximal Antenna RPM' calculated.
BITE Measurement Log Disk Limit
Reached
Error
Indicates that the amount of disk space allocated to the BITE
Measurement Log has been used up
BITE Status Log Disk Limit
Reached
Error
Indicates that the amount of disk space allocated to the BITE
Status Log has been used up
BITE Warning and Error Log Disk
Limit Reached
Error
Indicates that the amount of disk space allocated to the BITE
Warning and Error Log has been used up
CAN Bus Status#Motor Controller Error
Cancelable Call Warning#Motor
Controller
Warning
Chirp Reference Level Low Er-
ror#f0
Error
Indicates that the power of the transmitted signal as seen by the
receiver is lower than expected.
Chirp Reference Level Low Er-
ror#f1
Error
Indicates that the power of the transmitted signal as seen by the
receiver is lower than expected.
Chirp Reference Level Low Er-
ror#f2
Error
Indicates that the power of the transmitted signal as seen by the
receiver is lower than expected.
Chirp Reference Level Low Er-
ror#f3
Error
Indicates that the power of the transmitted signal as seen by the
receiver is lower than expected.
Clutter Map Input Link Error Could not connect to data input source.
Comm Error#Motor Controller Error
Command Error#Motor Controller Error
Communication Error#Motor Con-
troller
Error
