AUSTRALIA 2
Specifications
The maximum rating for the Wall Connector is 10 kW or 40 amps at 240 volts. Your vehicle can
charge from 180 to 265 volts.
Voltage and Wiring 240V AC single-phase: LINE, NEUTRAL, and EARTH
Current Maximum 50A circuit breaker
Frequency 50 -60 Hz
Cable Length Approximately 7.6 m
Wall Connector Dimensions Height: 385 mm
Width: 157 mm
Depth: 100 mm
Bracket Dimensions Height: 382 mm
Width: 158.2 mm
Depth: 96 mm
Weight (including bracket) 9 kg
Operating Temperature -30°C to 45°C
Storage Temperature -50°C to 85°C
Enclosure Rating IP 44
Agency Approvals CE
