To Next PageTo Next PageWhat to do if Tesla Battery Charger fails the internal self-check?
If the Wall Connector doesn't pass its self-check, unplug it from the car and press the RESET button. Then, plug it back into the car. If the error continues, unplug the Wall Connector, power it off, power it back on, and then plug it back into the car.
What to do if Tesla Battery Charger shows ground fault?
If your Tesla Wall Connector indicates a ground fault, which means current is unsafely leaking, try disconnecting the Wall Connector from your vehicle and then reconnecting it. If the issue remains, turn OFF the circuit breaker for the Wall Connector, wait for about 10 seconds, and then turn the breaker back ON. After that, try reconnecting the Wall Connector to your vehicle. The cause may be a Line to ground or Neutral to ground fault. If the problem continues after these steps, further assistance is needed.
Why is my Tesla Battery Charger reducing current due to high temperature?
The charging current might be reduced because high temperature was detected inside the Wall Connector. Ensure that the Wall Connector isn't covered and that there isn't a heat source nearby. If the problem continues even when the ambient temperature is normal (below 100°F or 38°C), further assistance is needed.
Why is my Tesla Battery Charger reducing current due to high temperature in the vehicle connector?
The charging current is possibly being reduced because a high temperature has been detected in the Vehicle Connector. To resolve this: * Ensure the connector is fully inserted into the vehicle's charging port. * Make sure the connector is not covered. * Verify there is no nearby heat source. If the issue continues in normal ambient temperatures (under 100°F or 38°C), further assistance is needed.
Why is my Tesla Battery Charger reducing current due to high temperature in the wall plug?
The charging current is possibly being reduced because a high temperature has been detected in the wall plug or on the input terminals to the Wall Connector. If the Wall Connector is hard-wired, make sure that it is not covered and there is no heat source nearby. If the problem continues even when the ambient temperature is normal (under 100°F or 38°C), further assistance is needed.
What to do if Tesla Battery Charger has over current protection?
If your Tesla Wall Connector indicates over current protection, reduce the vehicle's charge current setting. If the problem continues and the attached vehicle is manufactured by Tesla, further assistance is needed. If the attached vehicle is not manufactured by Tesla, contact the original manufacturer.
What to do if Tesla Automobile Accessories Wall Connector lost ground?
If your Tesla Automobile Accessories Wall Connector loses ground, ensure the power outlet is properly grounded and that the hot and neutral pins are correctly wired. If you're uncertain, consult your electrician.
What to do if Tesla Battery Charger shows 'contactor failed' error?
If the Tesla Wall Connector indicates a contactor failure, unplug it from the car and wait 10 seconds. If the error persists, contact Tesla.
What to do if Tesla Battery Charger shows a ground fault error?
If your Tesla Battery Charger indicates a ground fault, which means electrical current is leaking unsafely, it should automatically reset in 15 minutes. If it doesn't reset, ensure no one is touching the car and then press the RESET button.
What causes Tesla Battery Charger hardware failure?
Tesla Wall Connector hardware failure can occur due to several reasons: * Contactor failure * Self-test failure in CCID circuitry * Other hardware issues such as MCU, 3V3output, or the thermal sensor. Further assistance is needed.
Critical safety warnings for installation and operation of the Wall Connector, covering hazards.
Important cautions regarding potential damage, operational limits, and handling of the Wall Connector.
Guidance on selecting circuit breaker ratings for optimal charging speed and performance.
Details on the Wall Connector's automatic diagnostic and fault recovery capabilities.
Explanation of how the Wall Connector manages charging resumption after power interruptions.
Essential instructions for proper grounding to ensure safety and functionality.
Verification of all components included in the Wall Connector shipping box.
Instructions for securely mounting the Wall Connector bracket to the wall.
Steps to prepare the Wall Connector unit for mounting and wiring.
Procedure for attaching the Wall Connector unit to the installed wall bracket.
Detailed guide for connecting the electrical wiring to the Wall Connector.
Instructions for configuring the Wall Connector's operating current using DIP switches.
Procedure to verify the correct installation and initial operation of the Wall Connector.
Final steps to secure the unit's cover and restore power after installation.
Instructions for installing the accessory cable hanger for neat storage.
General| Amperage | 48 A |
|---|---|
| Current | AC |
| Connectivity | Wi-Fi |
| Compatibility | All Tesla vehicles |
| Connector Type | Tesla proprietary connector |
| Operating Temperature | -30°C to 50°C |
| Enclosure Rating | NEMA 3R |
| Installation Type | Wall-mounted |
| Maximum Power Output | 11.5 kW |
| Cable Length | 24 feet (7.3 meters) |
