CHINA MAINLAND, HONG KONG 2
Specifications
The maximum rating for the Wall Connector is 10 kW or 40 amps at 220 volts. Your vehicle can
charge from 180 to 265 volts.
Voltage and Wiring 220V AC single-phase: LINE, NEUTRAL, and EARTH
Current Maximum 50A circuit breaker
Frequency 50 Hz
Cable Length Approximately 7.6 m
Wall Connector Dimensions Height: 385 mm
Width: 157 mm
Depth: 100 mm
Bracket Dimensions Height: 382 mm
Width: 158.2 mm
Depth: 96 mm
Weight (including bracket) 9 kg
Operating Temperature -30°C to 45°C
Storage Temperature -50°C to 85°C
Enclosure Rating IP 44
Agency Approvals CE
Wall_Connector_Install_Guide_China_1039343-00-B.book Page 2 Thursday, July 17, 2014 10:56 AM
