TESTO 325M - Operation Summary; Unit Selection Summary; Flue Gas Measurement Summary; Draught Measurement Summary

Selecting uunits
11
Select
Unit in main menu and press to confirm.
22
Select parameter via / and confirm selection via .
33
Set unit via , change to next parameter via .
44
Press to confirm settings.
Measuring fflue ggases
11
Press to start measurement.
22
Press / to change between the options possible.
33
Press to end measurement.
Measuring ddraught
11
Select
Delta P in main menu and press to confirm.
22
Use / to select pressure range
Delta P1 (0 to 40hPa) or
Delta P2 (0 to 200hPa) and press to confirm.
- The analyser runs zeroing.
33
Insert probe pipe in flue gas duct.
- The current reading is displayed.
44
Press to end measurement.
Measuring ggas fflow ppressure
Pressure set (0554 0315) required. Procedure same as for draught
measurement.
Printing rreadings ttaken
Testo printer (0554 0545) required.
Start printing by activating in measurement menu.
Saving/reading/deleting rreadings ((
testo 325XL
only)
11
Select Memory in main menu and press to confirm.
22
Use / to select memory block and confirm via .
33
Select
Write, Read or Delete via / and press to
confirm.
Confirm clearance query with .
Printing ssaved rreadings ((
testo 325XL
only)
Testo printer (0554 0545) required.
11
Display readings (See: saving/reading readings).
22
Activate to start printing.
testo AG
Postfach 11 40, D-79849 Lenzkirch
Testo-Straße 1, D-79853 Lenzkirch
Tel. (0 76 53) 6 81 - 0
Fax (0 76 53) 6 81 - 1 00
E-Mail: info@testo.de
http://www.testo.de
0971.3257/01/T/dr/01.04.2004
