1
Insert the flue gas probe in the flue.
The thermocouple must always be exposed to the stream of flue gas to allow an
exact measurement of the flue gas temperature and thereby a precise determination
of the flue gas losses. It must not be screened by a web of the probe pipe.
2
Assign to function key.
3
Start measurement by pressing .
-
A measurement which is in progress is indicated by a flashing o.
4
The measurement is halted by activating .
-
The values are “frozen”.
Print readings by pressing the function key .
Store reading with – manual saving of separate measurements.
6.1.4 Reading out stored readings
1
–> –> .
2
Select readings and confirm with key.
3
Click on to return to measurement display.
Read ooutMemory
Save
Print
PStop
PStart
PStart
6. Measurement examples
37
Measurement in progress
