6 Using the product
43
4. Enter values: [▲], [▼] and sometimes [◄], [►] → [OK].
- Particulate matter probe is preheated to 50 °C (status display
flashes green).
- Measurement system is operational (status display lights up
green).
5. [Next]
Adjustment help measurement: continue with point 9
Compliance measurement: continue with point 6
Approval test: continue with point 6
6. Start draught measurement: [Start].
- Draught zeroing.
7. Position the particulate matter probe in the centre of flow (area
of the highest flue gas temperature).
The display showing the maximum measured flue gas
temperature (FT max) helps when positioning the probe.
- The reading is displayed.
8. End draught measurement: [Stop]
9. [Next]
If the message Stability not yet achieved. Please wait…
appears, do not start any measurement until the message
is no longer displayed.
10. Start measurement: [Start ].
- The stability time (approx. 3 min) elapses. Following this, the
measuring phase begins automatically.
The measuring phase can be interrupted early:
> press [Canc.].
Options
> Mean: the mean values of a measurement are
displayed.
> New: The measurement is restarted.
- The measurement result is displayed once the measuring
phase has been completed
11. Prepare the instrument for rinsing.
> Remove particulate matter probe from the flue gas duct →
[OK].
- Rinsing starts
12. Clean the sensor module, .
