Teuco 620 - Control Panel Details; Starting Up First Time - Version with Sand Filter

32
EN
620
1. 
See “Minipool Canvas”.
2. 
Set the main switch to the “OFF” position.
3. 
Set the lter valve to position 0.
Close all section valves along the various pipelines.
DETAILS OF THE CONTROL PANEL
STARTING UP FIRST TIME - VERSION WITH SAND FILTER
               




Three position switch: MAN-STOP-AUTO
Function buttons
Heater
ON/OFF switch
Display
Led
Heater on/off indicator

ON/OFF

Conrm Technical
Assistance Menu operations Shift Key
