Table 3-15. TI 60-Pin Connector (J33) Pin-Out
Pin No. Signal Pin No. Signal
1 VCC3V3_R 31 MIPI_TRC_DAT06
2 MIPI_TMS_R 32 NC
3 JTAG_MIPI_TCK 33 MIPI_TRC_DAT07
4 MIPI_TDO_R 34 NC
5 MIPI_TDI_R 35 MIPI_TRC_DAT08
6 MIPI_EMU_RSTn 36 NC
7 MIPI_RTCK 37 MIPI_TRC_DAT09
8 MIPI_TRST#_R 38 JTAG_MIPI_EMU0
9 NC 39 MIPI_TRC_DAT10
10 NC 40 JTAG_MIPI_EMU1
11 NC 41 MIPI_TRC_DAT11
12 VCC_3V3_MIPI 42 NC
13 MIPI_TRC_CLK 43 MIPI_TRC_DAT12
14 NC 44 NC
15 DGND 45 MIPI_TRC_DAT13
16 DGND 46 NC
17 MIPI_TRC_CTL 47 MIPI_TRC_DAT14
18 MIPI_TRC_DAT19 48 NC
19 MIPI_TRC_DAT00 49 MIPI_TRC_DAT15
20 MIPI_TRC_DAT20 50 NC
21 MIPI_TRC_DAT01 51 MIPI_TRC_DAT16
22 MIPI_TRC_DAT21 52 NC
23 MIPI_TRC_DAT02 53 MIPI_TRC_DAT17
24 MIPI_TRC_DAT22 54 NC
25 MIPI_TRC_DAT03 55 MIPI_TRC_DAT18
26 MIPI_TRC_DAT23 56 NC
27 MIPI_TRC_DAT04 57 DGND
28 NC 58 SEL_XDS100_INV
29 MIPI_TRC_DAT05 59 NC
30 NC 60 NC
System Description www.ti.com
24 AM64x/AM243x GP EVM User's Guide SPRUIX0C – FEBRUARY 2021 – REVISED JUNE 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated
