6.2 Bill of Materials
The bill of materials for the circuit module is shown in Table 6-1. Substitute parts may be used in the manufacturing of the assembly.
Table 6-1. BQ76922 Circuit Module Bill of Materials
Designator Qty Value Description Package Reference Part Number MFG
Alternate
Part Number
Alternate
MFG
!PCB1 1 Printed Circuit Board BMS022 Any
C1 1 0.47uF CAP, CERM, 0.47 uF, 25 V, +/- 10%, X7R, AEC-Q200 Grade
1, 0805
0805 GCM219R71E474KA55D MuRata
C2, C13 2 100pF CAP, CERM, 100 pF, 50 V, +/- 5%, C0G/NP0, 0603 0603 C0603C101J5GACTU Kemet
C3, C6 1 1uF CAP, CERM, 1 uF, 50 V, +/- 10%, X7R, AEC-Q200 Grade 1,
1206
1206 CGA5L3X7R1H105K160A
B
TDK
C4, C5, C7, C8, C9,
C10
6 0.22uF CAP, CERM, 0.22 uF, 50 V, +/- 10%, X7R, 0603 0603 C1608X7R1H224K080AB TDK
C19, C24, C25, C26, C27, C28, C29,
C30, C31, C32, C33, C34
12 0.1uF CAP, CERM, 0.1 uF, 50 V, +/- 10%, X7R, 0603 0603 885012206095 Wurth Elektronik
C11 1 0.022uF CAP, CERM, 0.022 uF, 16 V, +/- 10%, X7R, 0603 0603 C0603C223K4RACTU Kemet
C12
1
0.01uF CAP, CERM, 0.01 uF, 16 V, +/- 10%, X7R, 0603 0603 885012206040 Wurth Elektronik
C16 1 1uF CAP, CERM, 1 uF, 16 V, +/- 10%, X7R, 0805 0805 EMK212B7105KG-T Taiyo Yuden
C18 1 2.2uF CAP, CERM, 2.2 uF, 16 V, +/- 10%, X7R, 0805 0805 EMK212B7225KG-T Taiyo Yuden
C35, C37, C40, C41, C43 5 0.1uF CAP, CERM, 0.1 uF, 16 V, +/- 10%, X7R, 0402 0402 885012205037 Wurth Elektronik
C36, C42, C44 3 0.47uF CAP, CERM, 0.47 uF, 6.3 V, +/- 10%, X5R, 0402 0402 04026D474KAT2A AVX
C38, C39 2 10uF CAP, CERM, 10 µF, 16 V,+/- 10%, X5R, 0805 0805 CL21A106KOQNNNG Samsung Electro-Mechanics
C45 1 2200pF CAP, CERM, 2200 pF, 10 V, +/- 10%, X7R, 0402 0402 885012205008 Wurth Elektronik
D1, D2, D7 3 40V Diode, Schottky, 40 V, 0.2 A, SOT-323 SOT-323 BAS40W-7-F Diodes Inc.
D3 1 Red LED, Red, SMD LED_0603 150060RS75000 Wurth Elektronik
D4, D5, D6 3 16V Diode, Zener, 16 V, 500 mW, SOD-123 SOD-123 MMSZ5246B-7-F Diodes Inc.
D8 1 100V Diode, Ultrafast, 100 V, 0.15 A, SOD-123 SOD-123 1N4148W-7-F Diodes Inc.
D9 1 100V Diode, Schottky, 100 V, 0.15 A, SOD-123 SOD-123 BAT46W-7-F Diodes Inc.
D13, D14, D15 3 Green LED, Green, SMD LED_0603 150060VS75000 Wurth Elektronik
H1, H2, H3, H4 4 Bumpon, Hemisphere, 0.44 X 0.20, Clear Transparent Bumpon SJ-5303 (CLEAR) 3M
J1 1 TERM BLOCK 3.5MM VERT 6POS PCB HDR6 OSTTE060161 On Shore Technology
J2 1 Terminal Block, 3.5mm, 8-Pos, TH Terminal Block, 3.5mm, 8-Pos,
TH
ED555/8DS On-Shore Technology
J4 1 Header, 100mil, 6x2, Tin, TH Header, 6x2, 100mil, Tin PEC06DAAN Sullins Connector Solutions
J3 1 Header, 2.54mm, 3x1, Gold, SMT Header, 2.54mm, 3x1, SMT 87898-0304 Molex
J5 1 Header (friction lock), 100mil, 4x1, R/A, TH 4x1 R/A Header 22/05/3041 Molex
J7, J16 2 Header, 100mil, 5x2, Tin, TH Header, 5x2, 100mil, Tin PEC05DAAN Sullins Connector Solutions
J6 1 Header, 100mil, 4x2, Tin, TH Header, 4x2, 100mil, Tin PEC04DAAN Sullins Connector Solutions
J9 1 TERM BLOCK 3.5MM VERT 4POS PCB HDR4 OSTTE040161 On Shore Technology
J12 1 Receptacle, Micro-USB Type B, 0.65 mm, 5x1, R/A, Bottom
Mount SMT
Receptacle, 0.65mm, 5x1,
R/A, SMT
47346-1001 Molex
J13 1 Header, 2.54 mm, 2x1, Gold, TH Header, 2.54mm, 2x1, TH 61300211121 Wurth Elektronik
J15 1 Header, 2.54mm, 4x1, Tin, TH Header, 2.54mm, 4x1, TH 22284043 Molex
