Table 6-1. BQ76922 Circuit Module Bill of Materials (continued)
Designator Qty Value Description Package Reference Part Number MFG
Alternate
Part Number
Alternate
MFG
Q1 1 80 V Transistor, NPN, 80 V, 1 A, SOT-89 SOT-89 BCX5616TA Diodes Inc.
Q4, Q5 2 -60V MOSFET, P-CH, -60 V, -0.9 A, SOT-23 SOT-23 ZXMP6A13FTA Diodes Inc. None
Q7, Q8 2 60V MOSFET, N-CH, 60 V, 172 A, DNK0008A (VSON-CLIP-8) DNK0008A CSD18532Q5B Texas Instruments None
Q9 1 60V MOSFET, N-CH, 60 V, 0.31 A, SOT-323 SOT-323 2N7002KW Fairchild Semiconductor None
Q10 1 60V MOSFET, N-CH, 60 V, 2 A, AEC-Q101, SOT-23 SOT-23 DMN6075S-7 Diodes Inc. None
R1, R14, R15, R21, R23, R28 6 100 RES, 100, 5%, 0.1 W, AEC-Q200 Grade 0, 0603 0603 CRCW0603100RJNEA Vishay-Dale
R2, R4, R5, R6, R7, R8 6 20.0 RES, 20.0, 1%, 0.25 W, AEC-Q200 Grade 0, 1206 1206 CRCW120620R0FKEA Vishay-Dale
R3 1 200 RES, 200, 5%, 1 W, AEC-Q200 Grade 0, 2512 2512 CRCW2512200RJNEG Vishay-Dale
R11, R12, R13, R18, R19, R20, R22,
R46, R50, R55, R56, R57, R58, R59
14 10k RES, 10 k, 5%, 0.1 W, AEC-Q200 Grade 0, 0603 0603 CRCW060310K0JNEA Vishay-Dale
R16, R17, R24 3 100k RES, 100 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 0603 CRCW0603100KFKEA Vishay-Dale
R25 1 0.001 RES, 0.001, 1%, 1 W, 1210 1210 PMR25HZPFV1L00 Rohm
R29, R30 2 1.0k RES, 1.0 k, 5%, 1 W, AEC-Q200 Grade 0, 2512 2512 CRCW25121K00JNEG Vishay-Dale
R10, R31, R32, R38, R39, R40 6 10Meg RES, 10 M, 5%, 0.1 W, AEC-Q200 Grade 0, 0603 0603 CRCW060310M0JNEA Vishay-Dale
R33, R35, R37, R41, R42, R51 6 1.0k RES, 1.0 k, 5%, 0.1 W, AEC-Q200 Grade 0, 0603 0603 CRCW06031K00JNEA Vishay-Dale
R36 1 3.9k RES, 3.9 k, 5%, 0.25 W, AEC-Q200 Grade 0, 1206 1206 CRCW12063K90JNEA Vishay-Dale
R44 1 0 RES, 0, 5%, 0.1 W, AEC-Q200 Grade 0, 0603 0603 CRCW06030000Z0EA Vishay-Dale
R45, R47, R48, R49, R54 5 5.1k RES, 5.1 k, 5%, 0.1 W, AEC-Q200 Grade 0, 0603 0603 CRCW06035K10JNEA Vishay-Dale
R52 1 20k RES, 20 k, 5%, 0.1 W, AEC-Q200 Grade 0, 0603 0603 CRCW060320K0JNEA Vishay-Dale
R60, R61 2 33 RES, 33, 5%, 0.063 W, AEC-Q200 Grade 0, 0402 0402 CRCW040233R0JNED Vishay-Dale
R62 1 2.0k RES, 2.0 k, 5%, 0.063 W, AEC-Q200 Grade 0, 0402 0402 CRCW04022K00JNED Vishay-Dale
R63, R71 2 10k RES, 10 k, 5%, 0.063 W, AEC-Q200 Grade 0, 0402 0402 CRCW040210K0JNED Vishay-Dale
R64, R65 2 1.0Meg RES, 1.0 M, 5%, 0.063 W, AEC-Q200 Grade 0, 0402 0402 CRCW04021M00JNED Vishay-Dale
R66, R67, R68 3 330 RES, 330, 1%, 0.1 W, AEC-Q200 Grade 0, 0402 0402 ERJ-2RKF3300X Panasonic
R69, R70, R72, R73, R74 5 200 RES, 200, 1%, 0.25 W, AEC-Q200 Grade 0, 1206 1206 CRCW1206200RFKEA Vishay-Dale
RT1 1 10k Thermistor NTC, 10.0k ohm, 1%, Disc, 5x8.4 mm Disc, 5x8.4 mm 103AT-2 SEMITEC Corporation
S1, S2 2 Switch, Tactile, SPST-NO, SM Switch, 6.2X5X6.2 mm KST221JLFS C&K Components
S3 1 Switch, SPST-NO, Off-Mom, 0.05A, 12VDC, SMD 3.9x2.9mm PTS820 J20M SMTR LFS C&K Components
SH-J1, SH-J2, SH-J3, SH-J4, SH-J5,
SH-J6, SH-J7, SH-J8, SH-J9, SH-J10,
SH-J11
11 1x2 Shunt, 100mil, Gold plated, Black Shunt SNT-100-BK-G Samtec 969102-0000-DA 3M
TP1 1 Test Point, Multipurpose, Red, TH Red Multipurpose Testpoint 5010 Keystone
TP4 1 Test Point, Multipurpose, Black, TH Black Multipurpose Testpoint 5011 Keystone
TP13, TP14, TP15, TP16 4 Test Point, Compact, Black, TH Black Compact Testpoint 5006 Keystone
U1 1 Multicell Battery Monitor and Protection Family, RSN0032B
(WQFN-32)
RSN0032B BQ76922RSNT Texas Instruments BQ76922RSNR Texas
Instruments
U2, U3 2 Single-Channel ESD in 0402 Package With 10pF
Capacitance and 6V Breakdown, DPY0002A (X1SON-2)
DPY0002A TPD1E10B06DPYR Texas Instruments TPD1E10B06DP
YT
Texas
Instruments
U4 1 Family 2-5S Overvoltage Protector with Internal Delay Timer,
DPJ0008A (WSON-8)
DPJ0008A BQ771807DPJR Texas Instruments BQ771807DPJT Texas
Instruments
U5 1 25 MHz Mixed Signal Microcontroller with 128 KB Flash, 8192
B SRAM and 63 GPIOs, -40 to 85 degC, 80-pin QFP (PN),
Green (RoHS & no Sb/Br)
PN0080A MSP430F5529IPN Texas Instruments
