Table 6-1. BQ76922 Circuit Module Bill of Materials (continued)
Designator Qty Value Description Package Reference Part Number MFG
Alternate
Part Number
Alternate
MFG
U6, U7, U9, U10 4 Single-Channel ESD in 0402 Package With 10pF
Capacitance and 6V Breakdown, DPY0002A (X1SON-2)
DPY0002A TPD1E10B06DPYT Texas Instruments TPD1E10B06DP
YR
Texas
Instruments
U8 1 Single Output LDO, 150 mA, Fixed 3.3 V Output, 2.7 to 10
V Input, with Low IQ, 5-pin SOT-23 (DBV), -40 to 125 degC,
Green (RoHS & no Sb/Br)
DBV0005A TPS76333DBVR Texas Instruments
Y1 1 Resonator, 4 MHz, 39 pF, AEC-Q200 Grade 1, SMD 4.5x1.2x2 mm CSTCR4M00G55B-R0 MuRata
C17 0 0.01uF CAP, CERM, 0.01 uF, 16 V, +/- 10%, X7R, 0603 0603 885012206040 Wurth Elektronik
C14, C15, C20, C21 0 0.1uF CAP, CERM, 0.1 uF, 50 V, +/- 10%, X7R, 0603 0603 885012206095 Wurth Elektronik
D10, D11, D12 0 100V Diode, Schottky, 100 V, 0.15 A, SOD-123 SOD-123 BAT46W-7-F Diodes Inc.
F1 0 Fuse, 30 A, 62 VDC, SMD 9.5x2x5mm SFK-3030 Dexerials Corporation
FID1, FID2, FID3, FID4, FID5, FID6 0 Fiducial mark. There is nothing to buy or mount. N/A N/A N/A
J8 0 Terminal Block, 3.5mm Pitch, 2x1, TH 7.0x8.2x6.5mm ED555/2DS On-Shore Technology
J10, J11 0 Header, 2.54 mm, 7x1, Gold, TH Header, 2.54 mm, 7x1, TH PBC07SAAN Sullins Connector Solutions
J14 0 Header, 2.54mm, 5x1, Tin, TH Header, 2.54mm, 5x1, TH PEC05SAAN Sullins Connector Solutions
Q2 0 -60V MOSFET, P-CH, -60 V, -0.9 A, SOT-23 SOT-23 ZXMP6A13FTA Diodes Inc. None
Q3 0 40V MOSFET, N-CH, 40 V, 15 A, DQJ0008A (VSONP-8) DQJ0008A CSD18504Q5A Texas Instruments None
Q6 0 60V MOSFET, N-CH, 60 V, 172 A, DNK0008A (VSON-CLIP-8) DNK0008A CSD18532Q5B Texas Instruments None
R9 0 0 RES, 0, 5%, 0.1 W, AEC-Q200 Grade 0, 0603 0603 CRCW06030000Z0EA Vishay-Dale
R26 0 1.0k RES, 1.0 k, 5%, 1 W, AEC-Q200 Grade 0, 2512 2512 CRCW25121K00JNEG Vishay-Dale
R27 0 10Meg RES, 10 M, 5%, 0.1 W, AEC-Q200 Grade 0, 0603 0603 CRCW060310M0JNEA Vishay-Dale
R34 0 0 RES, 0, 5%, 2 W, 2512 WIDE 2512 WIDE RCL12250000Z0EG Vishay Draloric
R43 0 51 RES, 51, 5%, 0.1 W, AEC-Q200 Grade 0, 0603 0603 CRCW060351R0JNEA Vishay-Dale
R53 0 10k RES, 10 k, 5%, 0.1 W, AEC-Q200 Grade 0, 0603 0603 CRCW060310K0JNEA Vishay-Dale
TP38, TP39 0 Red Test Point, Compact, Red, TH Red Compact Testpoint 5005 Keystone
Note: Unless otherwise noted in the Alternate PartNumber and/or Alternate Manufacturer columns, all parts may be substituted with equivalents.
