Table 3-1. TPS25730EVM Bill of Materials (continued)
Designator Quantity Value Description Package Reference Part Number Manufacturer
R38, R46, R54,
R62
4 100k 100 kOhms ±1% 0.05W, 1/20W
Chip Resistor 0201 (0603 Metric)
Automotive AEC-Q200 Thick Film
0603 ERJ-1GNF1003C Panasonic Electronic
Components
R39, R47, R55,
R63
4 1k RES, 1.00 k, 1%, 0.05 W, 0201 0201 RC0201FR-071KL Yageo America
R40, R48, R56,
R64
4 5.1k RES, 5.10 k, 1%, 0.05 W, 0201 0201 RC0201FR-075K1L Yageo America
R41, R49, R57,
R65
4 12.1k RES, 12.1 k, 1%, 0.05 W, 0201 0201 RC0201FS-7D12K1L Yageo America
R42, R50, R58,
R66
4 23.2k RES, 23.2 k, 1%, 0.05 W, 0201 0201 RC0201FR-0723K2L Yageo America
R43, R51, R59,
R67
4 43.2k RES, 43.2 k, 1%, 0.05 W, 0201 0201 RC0201FR-0743K2L Yageo America
R44, R52, R60,
R68
4 115k RES, 115 k, 1%, 0.05 W, 0201 0201 RC0201FR-07115KL Yageo America
R45, R53, R61,
R69
4 412k RES, 412 k, 1%, 0.05 W, 0201 0201 RC0201FR-07412KL Yageo America
SH-J1, SH-J2,
SH-J3, SH-J4
4 Shunt, 100mil, Flash Gold, Black Shunt, 100mil, Flash Gold,
Black
SPC02SYAN Sullins Connector Solutions
SW1 1 Tactile Switch SPST-NO Top Actuated
Surface Mount
Tactile Switch SPST-NO Top
Actuated Surface Mount
B3U-1000P-B Omron
SW2, SW3,
SW4, SW5
4 Ultra-miniature Surface Mount Half-
pitch DIP Switch, -40 to 85 degC, 16-
Pin SMD (DIP), RoHS, Tube
SMD, 16-Leads, Body
11.29x6.2mm, Pitch 1.27mm
TDA08H0SB1 C&K Components
U1 1 USB Type-C and USB PD Controller
with Integrated Power Switches
Optimized for Power Applications
RJK0038B-MFG TPS25730DRJKR Texas Instruments
U2 1 22 V 22-V Precision Surge Protection
Clamp, DRV0006A (WSON-6)
DRV0006A TVS2200DRVR Texas Instruments
