2.7.1 Minimum Voltage Configuration
The minimum voltage for the USB Power Delivery Sink Capabilities can be set according to the table below.
When the received USB PD Source Capabilities do not meet the minimum and maximum voltage range the
Capabilities Mismatch bit is set on the USB PD request. When the Minimum Voltage is set greater than 5 V the
Higher Capability bit is set in the Sink Capabilities.
Table 2-7. Minimum Voltage Configuration for Sink Capabilities - ADCIN1 Decoded
ADCIN1 Decoded Value Minimum Voltage Configuration
0 5 V
1 9 V
2 12 V
3 15 V
4 20 V
5 Reserved
6 Reserved
7 Reserved
2.7.2 Maximum Voltage Configuration
The maximum voltage for the USB Power Delivery Sink Capabilities is set according to the table below.
When the received USB PD Source Capabilities do not meet the minimum and maximum voltage range the
Capabilities Mismatch bit is set on the USB PD request.
Table 2-8. Maximum Voltage Configuration for Sink Capabilities - ADCIN2 Decoded
ADCIN2 Decoded Value Maximum Voltage Configuration
1 9 V
3 12 V
5 15 V
7 20 V
