PACKAGE MATERIALS INFORMATION
www.ti.com 8-Jun-2022
TAPE AND REEL BOX DIMENSIONS
Width (mm)
W
L
H
*All dimensions are nominal
Device Package Type Package Drawing Pins SPQ Length (mm) Width (mm) Height (mm)
TPS65982ABZBHR NFBGA ZBH 96 2500 336.6 336.6 31.8
Pack Materials-Page 2
