Speech Dialler Installation Manual
10 INS232-2
Commissioning
1. Once all necessary connections have been made to the unit, re-connect the
loudspeaker to the main circuit board and clip the cover on to the base taking
care not to trap any cables.
2. Re-apply mains power to the control panel and reconnect the battery.
3. The dialler will enter its initialisation mode (15 seconds), during which you can:
• Press the red record
! key 5 times to load the factory default parameters
then the
" key. The display will show: “!"#$%&'()'*+,,,
-"#$.#)/$&0,,,”.
• Press the
# key to select the language then " key to accept.
4. After the unit has finished initializing/loading defaults the display will show
“,,,,1&.$2"#1,,,,”. The unit will beep once if it is a Speech Dialler and
twice if it is a Speech & Text Dialler. To select the programming mode enter the
default passcode of
$%&'.
5. The display will show “345)67).898:6;<)!7=6>:6)186>?9@” The unit is
now ready for programming and testing. Please refer to the “Operating
Instructions” for full details.
6. After the dialler has been programmed and tested, secure the front cover with
screw and screw cap that is provided in the spares pack.
Specifications
Supply Voltage: 10 - 14VDC
Current Consumption: 35mA (Standby), 100mA (Active)
Trigger Inputs: 4; +ve applied or +ve removed (5 - 24VDC)
Outputs: 2; Open collector switched –ve @100mA
Telecommunications Approval: CTR21
REN Rating: 1
Dialling Formats: Pulse or DTMF
Dimensions: 140mm x 115mm x 30mm
Packed Weight: 360g (Approximately)
