EN
2-THREAD SPREADER INSTALLATION
The hand wheel rotates along the direction of the
arrow until upper looper is on the right side of upper
knife.
Insert the hinge A in the 2-thread spreader into the
hole in the upper looper.
Turn the 2-thread spreader to the left and press the
upper part slightly back. The tip of the 2-thread
spreader will be locked in the hole of the upper
looper. With the reverse step, you can remove the
2-thread spreader.
Sewing 2-thread, 3-thread, 4-thread, must be
installed 2-thread spreader. The 2-thread spreader is
put in the accessories box.
NOTE: TURN OFF THE POWER.
Texi Integra 5102
